| Pipeline | O2, N2O and Reserved O2 |
|---|---|
| Yoke (optional) | 1 x O2 , I x N2O |
| Pressure gauge | 2 for pipeline gas; 2 for cylinder gas(optional) |
| Flowmeter | O2 & N2O; Mechanical 4 tubes; O2&N2O linkage and N2O cutoff system |
| O2 | 0~1L/Min, 1~10L/Min |
| N2O | 0~1/Min, 1~10/Min |
| O2 flush | 25-75L/min |
| Operational modes | Closed and Semi-closed circuit system |
| APL valve | 0.19~6KPa |
| Manual (Bag) / Mechanical ventilation switch | By-stable type, switch between manual/spontaneous ventilation and ventilator |
| ACGO connector | ISO 22mm OD and 15mm ID |
| AGSS (optional) | Passive |
